A hydrogen peroxide sensor tells you what the sterilizing agent is doing inside the chamber while the cycle runs. A chemical indicator tells you whether a surface was exposed. A biological indicator tells you whether resistant spores were killed. Vaporized hydrogen peroxide (VHP) validation needs all three, in a defined relationship, and the part most often mis-specified is which spore you are actually challenging the cycle with. This guide covers the sensor specifications that matter, the standard that governs VHP processes, and where each monitoring tool sits.
Quick facts
- Vaisala's H₂O₂ measurement platform is the HPP270 series: HPP271 for vaporized hydrogen peroxide concentration, and HPP272 for concentration, relative saturation, relative humidity and temperature in one probe.
- Both models publish a measurement range of 0 to 2000 ppm, with stated accuracy of ±10 ppm or 5% of reading, whichever is greater, from 10 ppm upward between +10 °C and +25 °C.
- The sensor is heated and includes a chemical purge function, which is what allows use in condensing environments.
- VHP process validation is governed by ISO 22441:2022, published in August 2022.
- There is still no published ISO 11138 part for vaporized hydrogen peroxide biological indicators; ISO/DIS 11138-6:2026 remains a draft.
What a hydrogen peroxide probe actually measures
Vaisala's PEROXCAP sensing platform is the basis of the HPP270 series, described by the manufacturer as designed for demanding hydrogen peroxide bio-decontamination. Two probes make up the series, and the difference between them decides which one belongs on your cycle report:
| Parameter | HPP271 | HPP272 |
|---|---|---|
| Vaporized H₂O₂ concentration | Yes | Yes |
| Relative saturation (%RS) | No | Yes |
| Relative humidity and temperature | No | Yes |
| Measurement range | 0 … 2000 ppm | 0 … 2000 ppm |
| Measurement temperature range | +5 … +50 °C | +5 … +50 °C |
| Repeatability at +25 °C, up to 500 ppm | ±10 ppm | ±10 ppm |
| Accuracy at +10 … +25 °C, 10 … 2000 ppm | ±10 ppm or 5% of reading, whichever is greater | ±10 ppm or 5% of reading, whichever is greater |
| Factory calibration uncertainty at +25 °C, 500 ppm | ±10 ppm | ±10 ppm |
| Response time (T63) | 70 s | 70 s |
| Relative saturation accuracy at +25 °C | Not applicable | ±4 %RS |
Three specification details deserve attention during a validation review:
- Accuracy starts at 10 ppm. The published statement is that the measurement range runs from 0 to 2000 ppm, and that "the accuracy specifications are stated from 10 ppm onwards." A cycle phase that spends time below that floor should not be reported at the stated tolerance.
- The probe is not a safety instrument. Vaisala states plainly that the HPP270 series probes "are not intended for safety level ppm measurements." Exposure monitoring for worker protection is a separate measurement chain.
- Response time is part of the cycle argument. A T63 of 70 seconds means the reading lags a fast injection phase; when you are demonstrating that a setpoint was reached and held, the sensor's own time constant belongs in the analysis.
The chemical purge function is the manufacturer's answer to drift: the probe heats the sensor at intervals so absorbed chemical contaminants evaporate, and the sensor is warmed continuously to prevent condensation forming on it while hydrogen peroxide is present. Vaisala also publishes traceable calibration certificates per probe — two points for H₂O₂, three for humidity, one for temperature — which is the artefact an auditor will ask for.
Why relative saturation matters as much as the concentration
Relative saturation is the parameter that connects two different numbers: how much hydrogen peroxide is in the vapour, and how close that vapour is to condensing. A concentration reading alone cannot tell you whether a surface is being exposed to vapour or to a film of liquid, and the two do not behave the same way on a device.
That is the case for specifying HPP272 rather than HPP271 wherever the cycle has condensation risk, and for trending %RS alongside ppm rather than treating it as secondary data. It is also the reason the manufacturer's own guidance stresses keeping the probe powered whenever hydrogen peroxide is present — the heated sensor is what makes condensing conditions measurable at all.
How a VHP cycle is validated under ISO 22441:2022
ISO 22441:2022, "Sterilization of health care products — Low temperature vaporized hydrogen peroxide — Requirements for the development, validation and routine control of a sterilization process for medical devices," gives the process its own standard rather than borrowing one. Its scope covers the development, validation and routine monitoring and control of a low temperature sterilization process using vaporized hydrogen peroxide as the sterilizing agent, and its introduction notes that VH₂O₂ sterilizers process typically below 60 °C and are primarily used for thermolabile or moisture-sensitive medical devices.
Two exclusions define the edges of the standard:
- Processes using other sterilizing agents, or hydrogen peroxide solution combined with other chemicals as the sterilizing agent, are not addressed; ISO 14937 is the referenced route for such processes.
- Processes for inactivating the causative agents of spongiform encephalopathies are not addressed.
The practical consequence: if your process is hydrogen peroxide in vapour form, ISO 22441 is the validation framework. If it is a hydrogen peroxide solution mixed with another chemistry, you are outside that framework and need the general process validation route instead. Being able to state which of the two you are running is itself part of the validation rationale.
Where biological indicators fit, and which organism to use
Biological indicators are the lethality evidence in a VHP validation. Mesa Laboratories states the position directly in its technical note on indicators for vaporized hydrogen peroxide: the biological indicator is the only tool that can give a direct measurement of a spore log reduction during the validation process as required by regulatory agencies, and a D-value is provided by manufacturers as the measure of resistance.
Which spores the indicator carries is where the confusion lives, because the ISO 11138 series fixes an organism per modality, and there is no published part for hydrogen peroxide:
| Sterilization modality | Standard | Test organism as specified |
|---|---|---|
| Moist heat | ISO 11138-3:2017, clause 5.1 | Geobacillus stearothermophilus or equivalent strains |
| Ethylene oxide | ISO 11138-2:2017, clause 5.1 | Bacillus atrophaeus, Bacillus subtilis or equivalent strains |
| Dry heat | ISO 11138-4:2017, clause 5.1 | Bacillus atrophaeus or equivalent strains |
| Vaporized hydrogen peroxide | ISO/DIS 11138-6:2026 — draft, not published | Not yet fixed by a published ISO part |
For hydrogen peroxide, the market answer comes from the indicator manufacturers. Mesa Laboratories states that spores of Geobacillus stearothermophilus — and to a lesser extent Bacillus atrophaeus — are recognised for use in vaporized hydrogen peroxide indicators because they are more resistant to the process than the bioburden, and notes that two strains of Geobacillus stearothermophilus are in use, ATCC 12980 and ATCC 7953, with ATCC 12980 the more commonly used and the greater challenge. A commercially available self-contained indicator for hydrogen peroxide processes is documented by its manufacturer as carrying 10⁶ colony forming units of Geobacillus stearothermophilus with a 24-hour incubation read.
The operational rule that follows: never assume an organism from your steam workflow. Read the certificate of analysis for the lot you are running, and confirm that the resistance data matches the process you are validating. With the VHP-specific ISO part still in development — ISO/DIS 11138-6 went to vote with a close of voting of 3 August 2026 — the certificate, not a clause number, is the citable evidence today. For the other half of the decision — what a spore test tells you that a rapid enzyme readout does not — see our comparison of enzyme indicators and biological indicators.
Sensor, chemical indicator or spore test
| Question | Tool | What it cannot tell you |
|---|---|---|
| What concentration is the chamber holding right now? | Hydrogen peroxide probe (HPP271 or HPP272) | Whether the load is sterile |
| Is the vapour close to condensing at this location? | HPP272 relative saturation | Whether the geometry leaves cold spots |
| Did this surface see the process at all? | Chemical indicator, per ISO 11140-1:2014, which covers vaporized hydrogen peroxide among its listed modalities | How much lethality margin exists |
| Were resistant spores killed at the challenge location? | Biological indicator | Where the next weakest position is, without position mapping |
| Is the cycle drifting between runs? | Probe trend data plus indicator records | A release decision on their own |
The three tools answer three different questions, and a validation file that contains only one of them is thin in a way that becomes obvious during an audit.
What a Canadian facility should specify and record
- Probe model and parameters. State whether the installation measures concentration only or concentration plus relative saturation, and why.
- Calibration. Keep the calibration certificate and its points per parameter, and the date the next calibration is due.
- Cycle parameters. Record concentration, exposure time, temperature and the humidity or relative saturation band that defines the validated cycle.
- Indicator lots. Keep the certificate of analysis for each biological indicator lot, including organism, population and resistance data, plus the incubation temperature and time used.
- Chemical indicator class and standard reference. Record which ISO 11140-1 indicator type is used and where it was placed.
- Records retention. Design the log so the sterilizer record and the monitoring results can be produced together for the retention period your jurisdiction expects — Ontario's provincial guidance, for example, expects the log book to be kept for at least 10 years from the date of the last entry.
If you need to build the spore-testing side of that programme, the 24-hour self-contained 25-pack and the 3-hour fluorescence 50-pack cover routine monitoring at different turnaround requirements, and the Rapid Reader seed trial lets a site test a fluorescence readout workflow before committing to a reader. The Biological Indicator 5-pack trial at CA $12.99 suits a first evaluation, and the full range sits in the sterilization monitoring collection under the sterilization compliance hub.
Sources and verification
All links were retrieved and checked on 16 September 2026.
- Vaisala HPP270 series — technical data sheet — measurement range, accuracy, repeatability, response time and calibration points for HPP271 and HPP272.
- Vaisala — HPP272 product page — PEROXCAP description, chemical purge, three-parameter measurement.
- Vaisala — PEROXCAP measurement values, chemical purge and function — accuracy statement from 10 ppm; the statement that the probes are not intended for safety level ppm measurements.
- ISO 22441:2022 — scope, exclusions and introduction, preview copy — inclusions, exclusions, the ISO 14937 note, and the process temperature statement.
- Mesa Laboratories — biological indicators for vaporized hydrogen peroxide — recognised organisms, ATCC strains, spore log reduction and D-value.
- ISO 11138-3:2017 — moist heat, preview copy — clause 5.1 test organism.
- ISO 11138-2:2017 — ethylene oxide, preview copy — clause 5.1 test organism.
- ISO 11138-4:2017 — dry heat, preview copy — clause 5.1 test organism.
- prEN ISO 11138-6 / ISO/DIS 11138-6:2026 — draft title, publication date and close of voting.
- ISO 11140-1:2014 — chemical indicators, preview copy — modalities covered, including vaporized hydrogen peroxide.
- STERIS — VERIFY V24 self-contained biological indicator — organism, population and incubation time.
- Ontario provincial guidance — cleaning, disinfection and sterilization in all health care settings, May 2013 — biological monitoring requirements and log book retention.
Related reading
- ISO 11138 Series: BI Standards for Steam, EO and VHP Explained
- Hydrogen Peroxide Wipes in Healthcare: What Canadian Facilities Should Know
- 24-Hour Biological Indicators: Fast Sterilization Verification
- free Ontario sterilization compliance log
Frequently Asked Questions
What is the difference between the Vaisala HPP271 and HPP272 probes?
HPP271 measures vaporized hydrogen peroxide concentration only. HPP272 adds relative saturation, relative humidity and temperature, reporting three parameters from one instrument. Both share the same concentration range and accuracy specification. Sites with condensation risk in the cycle generally need the relative saturation measurement that only HPP272 provides.
Can a hydrogen peroxide sensor replace biological indicators?
No. A sensor measures the physical conditions inside the chamber during the cycle; it cannot demonstrate that resistant spores were killed. Indicators for vaporized hydrogen peroxide are a separate measurement chain, and the biological indicator is the tool that provides a direct spore log reduction measurement for validation.
Which spore is used in a vaporized hydrogen peroxide biological indicator?
Manufacturers of indicators for this modality point to Geobacillus stearothermophilus as the recognised organism, with Bacillus atrophaeus used to a lesser extent. There is no published ISO 11138 part for hydrogen peroxide yet, so the organism is not fixed by a clause number in that series. Confirm it on the certificate of analysis for the lot you are using.
Why does the accuracy specification start at 10 ppm?
Vaisala states the measurement range as 0 to 2000 ppm with accuracy of plus or minus 10 ppm, or 5% of reading, whichever is greater, and notes that the accuracy specifications are stated from 10 ppm onwards. Reading below that floor is possible, but it should not be reported at the stated tolerance.
Is the HPP270 series suitable for worker safety monitoring?
No. Vaisala states that the HPP270 series probes are not intended for safety level ppm measurements. Personnel exposure monitoring requires its own instrument chain and its own calibration regime.
What standard governs vaporized hydrogen peroxide sterilization validation?
ISO 22441:2022, published in August 2022, covers the development, validation and routine monitoring and control of low temperature sterilization using vaporized hydrogen peroxide as the sterilizing agent. Processes using hydrogen peroxide solution in combination with other chemicals are excluded and are directed to ISO 14937.
